TRANSMISSION - Housing Components
J-42parts diagramHousing Components
- 1Assemble in the order shown in the figure, referring to Assembly Note.
05U0JX-056 - 2Check the gearshift lever operation.
| Specification | Value |
|---|---|
| Tightening torque (upper-left group) | ≈304 - 451N·m |
| Tightening torque (mid-left group) | ≈186 - 245N·m |
| Tightening torque (mid group) | ≈157 - 226N·m |
| Tightening torque (lower group) | ≈76 - 108N·m |
Tightening torque (upper-left group)
304 - 451N·m
Tightening torque (mid-left group)
186 - 245N·m
Tightening torque (mid group)
157 - 226N·m
Tightening torque (lower group)
76 - 108N·m
NOTE
Sealant: MORI WHITE TA NO.2 OR EQUIVALENT ORGANIC MOLYBDENUM.
See also
Assembly Note
