HORN — STRUCTURAL VIEW

T-91component photo

STRUCTURAL VIEW

Component LocationFig. fig1

Horn system component locations on the MX-5.

Three-quarter front view of the MX-5 with two zoomed-in callout circles. Callout 1 (left) shows the horn unit mounted in the front engine bay near the radiator support. Callout 2 (right) shows the horn relay located near the steering column / fuse panel area under the dashboard. Numbered legend below lists 1. Horn, 2. Horn relay, 3. Horn switch.

05U0TX-328

11(Horn)

22(Horn relay)

33(Horn switch)
